Cabo Panasonic 3SR-CABLE-DHLC4-2 para placa DHLC4 — cabo de ligação de 2 portas

The Cable Panasonic 3SR-CABLE-DHLC4-2 for DHLC4 card — 2-port connection cable is a manufacturer-compatible wiring solution designed to connect two ports of a DHLC4 communication card. It provides a direct physical link between the card and associated devices or modules, intended for installation, replacement or maintenance in systems that require Panasonic compatibility. The cable is built to match the connection requirements of the DHLC4 card and to simplify integration into existing control or communication setups.

Advantages

This 2-port connection cable offers a straightforward, OEM-compatible interface that reduces installation time by matching the DHLC4 pinout and connector style. It supports reliable electrical continuity for both ports and minimizes the need for custom wiring or adapter components. The cable’s design helps maintain signal integrity and reduces the risk of miswiring during replacement or service operations.

Suitable for

Key specifications

How to use

Install the cable by aligning each connector with the corresponding DHLC4 card port and seating it firmly until it engages. Ensure equipment power is turned off before performing the connection to avoid electrical hazards. Route the cable inside the cabinet or enclosure to prevent mechanical strain or interference, using existing cable guides or tie points where available. After connecting both ports, restore power and verify communication between the DHLC4 card and connected devices according to the system’s diagnostic procedures.

Recommendations

Verify that the DHLC4 card model in your system matches the cable’s compatibility requirements before installation. Use appropriate ESD precautions and avoid sharp bends or excessive tension on the cable. If long-term or outdoor routing is needed, select additional protective conduits or shielding in accordance with site specifications.
