Caixa de parede Rittal AX 1077.000, IP55, cinzento-claro

Rittal AX 1077.000 is a compact, wall-mounted rack designed to house electrical and electronic equipment in industrial and commercial environments. The enclosure is made from sheet steel and finished in light grey, providing a robust surface for installations that require basic protection against dust and water. The cabinet complies with IP55 protection standards and follows the AX Basic enclosure concept with an internal 25 mm system pitch pattern compatible with the VX25 series, enabling simple configuration and retrofit of components without drilling.

Advantages

The AX compact enclosure offers a sturdy sheet-steel construction with an IP55 protection rating that shields installed components from dust and low-pressure water jets. Its integrated enclosure locators in the roof, base and side enable precise mounting of rails and accessories. The 25 mm system pitch and compatibility with VX25 components allow straightforward installation and retrofit of system parts and accessories, reducing installation time and simplifying maintenance. The light grey finish provides a neutral appearance suitable for a range of technical environments.

Suitable for

Key specifications

How to use

Mount the rack securely to a suitable wall substrate using appropriate fixings for the wall material and load. Install rails and accessories by engaging them with the integrated enclosure locators; the 25 mm system pitch allows positioning without drilling. Route cables through designated entry points or gland plates and secure equipment on the internal rails. Ensure all seals and doors are correctly closed to maintain the IP55 rating. Verify grounding and earthing connections according to local regulations before energising installed equipment.

Recommendations

For best results, select wall-fixings and load-bearing points based on the total weight of mounted equipment and any dynamic loads. Use appropriate cable glands and sealing accessories at entry points to preserve IP55 protection. When retrofitting modules, confirm compatibility with the 25 mm system pitch and follow manufacturer instructions for grounding and safe installation.
