Caixa de servidor Supermicro CSE-LA26AC12-R920LP1 rack 920W preto cinzento

The Supermicro CSE-LA26AC12-R920LP1 Rack 920W Black Grey is a compact 1U rackmount server chassis engineered for density and reliability. It includes an integrated 920W power supply and supports both 2.5" and 3.5" hard drives, providing flexibility for mixed storage configurations. With a width of 437 mm, depth of 647 mm and a height of 89 mm, the case is designed to fit standard 19" racks while conserving horizontal rack space.

Advantages

The chassis combines a high-capacity 920W power unit with a slim 1U profile, enabling high power delivery in a space-efficient form factor. Support for multiple drive sizes allows easy migration between SSD and HDD media without requiring adapter trays. Its metal construction and standardized rack dimensions ensure mechanical compatibility and stable mounting in server cabinets. The included power supply reduces the need for separate PSU procurement and simplifies initial deployment.

Suitable for

• High-density server deployments in data centers and colocation racks
• Small and medium business server rooms requiring 1U form factor
• Storage-focused systems combining 2.5" SSDs and 3.5" HDDs
• Compute nodes that need a reliable integrated 920W power source

Key specifications

• Form factor: 1U rackmount chassis compatible with 19" racks
• Power supply: integrated 920W unit
• Drive bay support: 2.5" and 3.5" hard drives
• External dimensions (W x D x H): 437 mm x 647 mm x 89 mm
• Colour: black and grey finish
• Material: metal chassis for rack-mounted servers

How to use

Install the chassis into a standard 19" rack using appropriate mounting rails or rack ears, ensuring the unit is securely fastened and supported. Populate drive bays with 2.5" or 3.5" drives as required by your configuration, following the chassis guide for any required trays or brackets. Connect the integrated 920W power supply to a suitable UPS or PDU that supports the server's power requirements. Provide proper front-to-rear airflow in the rack and verify that cooling and cable management meet the data center or server room standards.

Recommendations

For reliable operation, pair the Supermicro CSE-LA26AC12-R920LP1 with a managed PDU and maintain unobstructed airflow in the rack. Use vibration-dampening mounting for mechanical drives and follow manufacturer guidelines for drive cooling and redundant power planning when used in critical environments.
