Câmara 5MP AHD HD-CVI HD-TVI PAL APTI-H54B varifocal 2,8-12 mm IR 40 m IP66

The APTI-H54B is a high-performance 5 Megapixel analog HD camera supporting multiple video output standards including AHD, HD-CVI, HD-TVI, and CVBS (PAL). Equipped with a 1/2.8" SONY IMX335 CMOS sensor, it delivers crisp and detailed images at resolutions up to 2592x1944. The varifocal lens (2.8-12 mm) allows flexible field-of-view adjustment, making it suitable for a wide range of surveillance applications.

Advantages

With true day/night functionality (ICR), 40m IR night vision range, and advanced noise reduction (2D/3D DNR), this camera ensures clear footage around the clock. The IP66-rated metal housing provides reliable protection against dust and water, enabling outdoor installation. Coaxial control via OSD simplifies configuration without additional wiring.

Suitable for

• Outdoor perimeter surveillance
• Commercial and residential security
• Parking lots and entrances
• Warehouse and industrial monitoring

Key specifications

• Sensor: 1/2.8" SONY IMX335 CMOS
• Resolution: 5 MP (2592x1944)
• Video Output: AHD / HD-CVI / HD-TVI / CVBS (PAL) selectable
• Lens: Varifocal 2.8-12 mm
• IR Range: Up to 40 m
• Minimum Illumination: 0.01 Lux (F1.2, AGC ON), 0 Lux with IR
• Day/Night: Auto (ICR), Color, B/W
• Noise Reduction: 2D/3D DNR
• WDR: DWDR
• BLC: Yes
• OSD: Yes (Coaxial Control)
• IP Rating: IP66
• Housing: Metal
• Power: DC 12V, max 700mA (IR ON)
• Operating Temperature: -20°C to +50°C
• Frame Rate: 5MP@20fps, 4MP@25/30fps, 2MP@25/30fps

Recommendations

For optimal performance, use a regulated DC 12V power supply and ensure proper cable connections. The camera supports coaxial control via DVR/NVR; refer to the user manual for OSD menu navigation.
