Câmara de vigilância IP Hikvision Pro Series DS-2CD2186G2H-ISU(2.8mm)(eF)/Preto

The Hikvision Pro Series DS-2CD2186G2H-ISU(2.8mm)(eF)/BLACK is an outdoor IP security camera offering 3840 x 2160 resolution in a bullet form factor. Designed for ceiling or wall mounting, the camera provides a wide horizontal field of view (105.1°), a vertical field of view (54.8°) and a 355° rotation range. Equipped with a CMOS sensor and a detection range up to 89 m, this wired black camera supports video motion detection and is intended for reliable perimeter and property surveillance.

Advantages

Integrated AcuSense deep-learning algorithms enable classification of human and vehicle targets to reduce false alarms and focus notifications on relevant events. High 4K resolution delivers clear image detail for identification, while a 30 fps frame rate ensures smooth video. The camera’s IP-outdoor placement support, wired Ethernet connectivity and compact 0.525 kg weight make it suitable for durable external installations.

Suitable for

• Perimeter and property surveillance
• Driveways and parking areas monitoring
• Commercial and residential outdoor entrances
• Sites requiring human/vehicle alarm classification

Key specifications

• Model: DS-2CD2186G2H-ISU(2.8mm)(eF)/BLACK
• Resolution: 3840 x 2160 (4K)
• Lens focal length: 2.8 mm
• Field of view: 105.1° horizontal, 54.8° vertical
• Rotation range: 355°
• Sensor: CMOS
• Frame rate: 30 fps
• Detection distance: up to 89 m
• Connectivity: wired Ethernet (no Wi‑Fi)
• Mounting: ceiling or wall
• Placement: outdoor
• Weight: 0.525 kg
• Colour: Black

How to use

Mount the camera on a stable ceiling or wall surface using appropriate fixtures and wiring for outdoor installations. Connect the device to a wired Ethernet network for power and data (PoE if supported by your system) and configure video settings, motion detection and AcuSense target classification through the Hikvision management interface or compatible NVR. Position the camera to cover the intended area, adjusting the lens angle within the 355° rotation range to achieve the required field of view.

Recommendations

For optimal classification performance, place the camera at a height and angle that provide unobstructed views of pedestrian paths and vehicle lanes, avoid strong backlighting, and perform periodic firmware updates and calibration via Hikvision tools.
