Célula de carga Kern CK 10-Y4, capacidade 10 kg, precisão C3, IP65, liga de alumínio

Accurate weight measurement in industrial and commercial scales depends on a reliable load cell. The Kern CK 10-Y4 is a single-point load cell engineered for platform scales up to 200 x 200 mm, delivering a rated capacity of 10 kg with C3 accuracy class for precise results.

Who is it for

This load cell suits scale manufacturers, system integrators, and service technicians who need a robust, high-precision sensor for bench scales, counting scales, and checkweighers. It is also suitable for upgrading or repairing existing weighing equipment.

Main features

• Rated load capacity: 10 kg
• Accuracy class C3 (OIML R60)
• Rated output: 2.0 mV/V ± 0.002 mV/V
• Input resistance: 400 ± 15 Ω
• Output resistance: 350 ± 3 Ω
• Insulation resistance: ≥ 5000 MΩ (50V DC)
• Recommended excitation voltage: 5-12 V DC
• Maximum excitation voltage: 15 V DC
• Material: aluminium alloy
• Protection class: IP65
• Operating temperature range: -20°C to +60°C
• Compensated temperature range: -10°C to +40°C
• Creep (30 min): ± 0.02% F.S.
• Temperature effect on zero: ± 0.02% F.S./10°C
• Temperature effect on sensitivity: ± 0.02% F.S./10°C
• Safe overload: 150% F.S.
• Ultimate overload: 300% F.S.
• Cable length: 3 m (4-core shielded)
• Maximum platform size: 200 x 200 mm

Specifications

• Rated load capacity: 10 kg
• Accuracy class: C3 (OIML R60)
• Rated output: 2.0 mV/V ± 0.002 mV/V
• Input resistance: 400 ± 15 Ω
• Output resistance: 350 ± 3 Ω
• Insulation resistance: ≥ 5000 MΩ (50V DC)
• Recommended excitation voltage: 5-12 V DC
• Maximum excitation voltage: 15 V DC
• Material: aluminium alloy
• Protection class: IP65
• Operating temperature range: -20°C to +60°C
• Compensated temperature range: -10°C to +40°C
• Creep (30 min): ± 0.02% F.S.
• Temperature effect on zero: ± 0.02% F.S./10°C
• Temperature effect on sensitivity: ± 0.02% F.S./10°C
• Safe overload: 150% F.S.
• Ultimate overload: 300% F.S.
• Cable length: 3 m (4-core shielded)
• Maximum platform size: 200 x 200 mm

Tips

For optimal performance, mount the load cell on a flat, rigid surface and ensure the platform is evenly loaded. Use a stable excitation voltage within the recommended range to maintain accuracy. Avoid exceeding the safe overload limit to prevent permanent damage.
