Combinador de cabos Televes VS40WD

The Televes VS40WD cable combiner is a compact passive device designed to operate across the 950–2150 MHz frequency range. With dimensions of 85 mm width, 25 mm depth and 70 mm height and a neutral grey finish, the unit integrates into various installation environments while combining multiple coaxial signals into a single output. The combiner is intended for use in distribution systems where combining satellite, CATV or other RF signals within the specified band is required.

Advantages

The Televes VS40WD combines multiple RF inputs into one output without active electronics, ensuring reliable passive operation across the 950–2150 MHz band. Its small footprint and grey housing enable discreet mounting in tight spaces and behind equipment racks. Passive construction eliminates the need for power, reducing maintenance and installation complexity. The device is built for stable impedance matching to minimise signal reflections and preserve signal quality when used within its frequency range.

Suitable for

Key specifications

How to use

Connect the incoming coaxial cables to the combiner’s input ports and attach the combined output to the receiver, distribution amplifier input or downstream equipment. Ensure all connectors are tightened to provide reliable electrical contact and maintain impedance continuity. Place the unit in a ventilated, dry location away from direct moisture and avoid mechanical stress on cables and connectors. Verify signal levels after installation to confirm that combined signals meet the receiving equipment’s input specifications.

Recommendations

Use the Televes VS40WD within its specified 950–2150 MHz range and in systems where passive combination is appropriate. For installations requiring amplification, filtering or isolation between sources consider adding dedicated active components upstream or downstream. Regularly inspect connectors and cable integrity to maintain optimal signal quality.
