Combo depósito-bomba EK Water Blocks EK-Quantum Kinetic3 FLT D5 PWM 360mm D-RGB

The EK-Quantum Kinetic3 FLT D5 PWM 360mm D-RGB is a combined reservoir and D5 PWM pump designed for custom PC liquid cooling systems. The cylindrical 360mm reservoir integrates a proven D5-class pump mechanism with PWM speed control and addressable D-RGB lighting, offering a compact, all-in-one solution for circulating coolant in single-loop or multi-loop configurations. The unit is engineered for straightforward integration into standard PC cases and mounting locations where a long cylindrical reservoir and reliable flow control are required.

Advantages

This reservoir pump combo provides a compact footprint with integrated pump electronics and PWM control, reducing the number of separate components to install and wire. The 360mm cylinder increases coolant capacity and improves air separation compared to smaller reservoirs. Addressable D-RGB illumination allows synchronized lighting with compatible motherboard or controller headers, while the D5-class pump delivers stable flow rates and proven long-term reliability. The design supports easy fill and bleed operations and minimizes tubing clutter in custom loops.

Suitable for

• Custom single-loop PC water-cooling systems that require an integrated reservoir and pump
• Compact builds where space-efficient vertical reservoir installation is preferred
• Systems needing PWM-controlled pump speed for thermal and acoustic balance
• Setups that use addressable RGB synchronization with compatible motherboard or controller headers

Key specifications

• Cylindrical reservoir, 360 mm length providing increased coolant volume
• Integrated D5-class pump with PWM speed control for precise flow adjustment
• Addressable D-RGB lighting for customizable illumination and synchronization
• Standard G1/4" threaded ports for inlet/outlet connections to typical fittings and tubing
• Robust housing materials compatible with common coolant types used in PC water cooling

How to use

Install the EK-Quantum Kinetic3 FLT D5 PWM 360mm D-RGB in a suitable vertical or horizontal mounting location inside the PC case, using the manufacturer’s mounting brackets and screws. Connect inlet and outlet ports to the loop using G1/4" fittings and appropriate tubing, ensuring secure seals. Wire the pump to a PWM-capable fan header or pump header on the motherboard to enable speed control, and connect the D-RGB cable to an addressable RGB header for lighting control. Fill the loop with compatible coolant, perform leak testing, and bleed air from the system before normal operation.

Recommendations

Use compatible coolants and regularly inspect fittings and tubing for signs of wear. Configure PWM curves on the motherboard or controller to balance cooling performance and noise. When integrating D-RGB lighting, confirm voltage and pinout compatibility with your controller to avoid lighting issues.
