Compatível Extreme Networks 10423 BlueLAN Cabo Breakout Direct Attach Passivo 100GBASE-CR4 QSFP28 para 4x25GBASE-CR SFP28, 3m, AWG26 (10423-BL)

This BlueLAN passive direct attach breakout cable (DAC) is designed for compatibility with Extreme Networks 10423 and other QSFP28/SFP28 compliant devices. It provides a cost-effective, low-power solution for high-speed data center interconnects and high-performance computing environments.

Advantages

Passive copper design ensures zero power consumption and ultra-low latency. The breakout configuration allows a single 100G QSFP28 port to connect to four 25G SFP28 ports, maximizing port density and flexibility. Hot-swappable for easy installation and maintenance.

Suitable for

• Data center interconnects
• High-performance computing (HPC) clusters
• Network switches and servers with QSFP28 and SFP28 interfaces

Key specifications

• Product Type: Direct Attach Breakout Cable (DAC)
• Cable Type: Passive Copper
• Aggregate Data Rate: 100 Gbps
• Channel Data Rate: 4x 25 Gbps
• Connector A: QSFP28
• Connector B: 4x SFP28
• Ethernet Standard (QSFP28): 100GBASE-CR4
• Ethernet Standard (SFP28): 25GBASE-CR
• Cable Length: 3 meters
• Wire Gauge: AWG26
• Hot-Swappable: Yes
• Protocol Support: Ethernet
• Power Consumption: 0W (Passive)
• RoHS Compliance: Yes

Recommendations

Ensure your equipment supports QSFP28 and SFP28 interfaces. This cable is ideal for upgrading to 100G connectivity while leveraging existing 25G infrastructure.
