Conector fêmea inversor de fases CEE MENNEKES 2511 16A 5P 6H 400V IP44

The MENNEKES 2511 phase inverter coupler is a robust solution for reversing phase rotation in three-phase systems without rewiring. Its integrated rotatable insert allows quick phase reversal, making it ideal for industrial and construction applications where motor direction must be changed frequently.

Highlights

• 16 A, 400 V, 5-pole (3P+N+PE) configuration
• Earth contact position at 6h for standard industrial compatibility
• IP44 splash-proof protection for demanding environments
• Durable polyamide housing and nickel-plated brass contacts
• Integrated phase reversal via rotatable insert

In daily use

Designed for cable-mounted use, this straight coupler provides a secure screw terminal connection and strain relief. It operates reliably in temperatures from -25°C to +40°C and meets IEC 60309 standards, ensuring safe performance on construction sites and in commercial settings.

Full specifications

• Current rating: 16 A
• Voltage rating: 400 V
• Number of poles: 5-pole (3P+N+PE)
• Earth contact position: 6h
• Ingress protection: IP44
• Housing material: Polyamide (PA6)
• Contact material: Brass, nickel-plated
• Colour: Red
• Connection type: Screw terminals
• Cable entry: Gland with strain relief
• Phase reversal function: Integrated via rotatable insert
• Standards: IEC 60309-1, IEC 60309-2
• Operating temperature range: -25°C to +40°C
• Rated frequency: 50/60 Hz
• Application: Industrial, Commercial, Construction Sites
• Design: Straight coupler
• Mounting type: Cable-mounted

Final note

This phase inverter coupler offers a practical and reliable solution for phase reversal in industrial power distribution, combining durability with ease of use.
