Controlador dimmer PWM de 4 canais Synergy 21 LED série EOS 05

The Synergy 21 LED Serie EOS 05 is a professional 4-channel PWM dimmer controller designed for precise control of LED lighting systems. It supports DMX512 protocol, making it ideal for stage, architectural, and commercial lighting applications. With a robust aluminum housing and screw terminal connections, this controller ensures reliable performance and easy installation.

Advantages

This controller offers high output current per channel (5A) and a wide dimming range (0-100%), providing smooth and flicker-free dimming. Its compact surface-mount design saves space, and the RJ45 DMX in/out ports allow for easy daisy-chaining of multiple units.

Suitable for

• RGB, RGBW, and single-color LED strips and modules
• Stage lighting, architectural accent lighting, and commercial displays
• DMX512-controlled lighting systems requiring up to 4 channels

Key specifications

• Product Type: LED Dimmer Controller
• Control Protocol: DMX512
• Number of Channels: 4
• Dimming Technology: PWM (Pulse Width Modulation)
• Input Voltage: DC 12-24V
• Output Current per Channel: 5A
• Total Output Current: 20A (4 x 5A)
• Max Output Power (12V): 240W (4 x 60W)
• Max Output Power (24V): 480W (4 x 120W)
• Dimming Range: 0-100%
• PWM Frequency: 400 Hz
• DMX Channels Used: 4
• Input/Output Connections: Screw Terminals (Power), RJ45 (DMX In/Out)
• Operating Temperature: -20°C to +50°C
• Housing Material: Aluminum
• Protection Class: IP20
• Mounting Type: Surface Mount

Recommendations

For optimal performance, use a regulated DC power supply matching the total power requirements. Ensure proper ventilation and avoid exposure to moisture. Compatible with standard DMX512 controllers and software.
