DAHUA CHS4110-8ET-90-F Switch PoE+ Industrial não gerido, 8x portas PoE 10/100Mbps + 2x Uplink Gigabit, orçamento 90W, calha DIN

The DAHUA CHS4110-8ET-90-F is a robust industrial unmanaged PoE+ switch designed for reliable network connectivity in harsh environments. With 8 Fast Ethernet PoE ports and 2 Gigabit uplink ports, it delivers power and data to devices such as IP cameras, access points, and VoIP phones over a single cable, simplifying installation and reducing costs.

Advantages

This switch offers a total PoE power budget of 90W, supporting IEEE 802.3af/at standards for flexible device powering. Its fanless design ensures silent operation and enhanced durability, while wide operating temperature range (-30°C to +65°C) and robust protection against ESD and surges make it ideal for industrial settings. The compact DIN-rail and wall-mount form factor saves space in control cabinets.

Suitable for

• Industrial automation networks
• Surveillance systems (IP cameras)
• Wireless access point deployments
• Smart city and transportation infrastructure
• Remote monitoring and control applications

Key specifications

• Ports: 8x 10/100Mbps PoE (802.3af/at) + 2x 10/100/1000Mbps uplink
• PoE Budget: 90W
• Switching Capacity: 5.6 Gbps
• Packet Forwarding Rate: 4.17 Mpps
• MAC Address Table: 8K entries
• Jumbo Frame Support: 10K bytes
• Operating Temperature: -30°C to +65°C
• Power Input: DC 48V–57V
• Mounting: DIN-rail, wall-mount
• Protection: ESD, Surge
• Certifications: CE, FCC

Recommendations

For optimal performance, use quality CAT5e or higher cabling and ensure proper grounding. The switch is unmanaged, making it plug-and-play; no configuration required. Ideal for edge deployments where reliability and simplicity are key.
