DEANTE caixa de encastrar Série A, 1 tomada, polipropileno, laranja, 71x71x42 mm, IP20

The DEANTE A Series flush-mounted installation box provides a robust and reliable housing for electrical switches and sockets in brick or concrete walls. Its self-extinguishing polypropylene construction ensures safety and durability in indoor installations.

Advantages

This single-gang box features multiple knock-out cable entries for flexible wiring, two fixing points for secure device mounting, and compliance with EN 60670-1 standards. The square design with a 40 mm internal depth accommodates standard accessories, while the IP20 rating protects against solid objects larger than 12.5 mm.

Suitable for

• Indoor electrical installations in residential and commercial buildings
• Flush mounting in brick and concrete walls using mortar or plaster
• Standard switches, sockets, and other single-gang devices

Key specifications

• Product Type: Flush-Mounted Installation Box
• Material: Polypropylene (PP), self-extinguishing
• Mounting Type: Flush-mounted (mortar/plaster-in)
• Number of Gangs: Single
• Shape: Square
• Colour: Orange
• Ingress Protection: IP20
• Temperature Resistance: -5°C to +60°C
• Cable Entries: Multiple knock-out entries
• Internal Depth: 40 mm
• External Dimensions: 71 x 71 x 42 mm (L x W x D)
• Fixing Points: 2 (for device screws)
• Standards Compliance: EN 60670-1
• Series: A Series

Recommendations

For a safe and code-compliant installation, pair this box with DEANTE A Series switches and sockets. Ensure proper sealing around the box to maintain the IP20 rating and use appropriate cable glands for knock-out entries.
