DEHN Wilson Electronics WILSON400 500 ft cabo coaxial de baixas perdas (952305)

Long coaxial runs for cellular boosters, Wi-Fi, two-way radio, and DAS systems often suffer from signal loss that degrades performance. The DEHN Wilson Electronics WILSON400 500 ft cable solves this with low-loss construction and double shielding, preserving signal integrity over 152.4 meters.

Who is it for

Installers and system integrators who need a bulk 50-ohm cable for outdoor or in-building RF distribution where cable length is significant and signal quality is critical.

Main features

• Low-loss WILSON400 series, equivalent to LMR-400
• Solid copper inner conductor, 10 AWG (2.74 mm)
• Foamed polyethylene dielectric for 85% velocity of propagation
• Double shielded: bonded aluminum foil plus tinned copper braid with 90% coverage
• UV-resistant polyethylene jacket, 0.405 in (10.29 mm) outer diameter
• Frequency range DC to 6 GHz
• Attenuation: 2.2 dB/100 ft @ 150 MHz, 5.8 dB/100 ft @ 900 MHz, 10.2 dB/100 ft @ 2400 MHz, 16.5 dB/100 ft @ 5800 MHz
• Minimum bend radius 4 in (10.2 cm) during installation
• Bulk cable, no connectors

Specifications

• Impedance: 50 Ω
• Length: 500 ft (152.4 m)
• Cable type: Low-loss coaxial
• Inner conductor: Solid copper, 10 AWG (2.74 mm)
• Dielectric: Foamed polyethylene (FPE)
• Shielding: Bonded aluminum foil + tinned copper braid (90% coverage)
• Jacket material: UV-resistant polyethylene (PE)
• Outer diameter: 0.405 in (10.29 mm)
• Velocity of propagation: 85%
• Frequency range: DC to 6 GHz
• Attenuation @ 150 MHz: 2.2 dB/100 ft
• Attenuation @ 900 MHz: 5.8 dB/100 ft
• Attenuation @ 2400 MHz: 10.2 dB/100 ft
• Attenuation @ 5800 MHz: 16.5 dB/100 ft
• Minimum bend radius: 4 in (10.2 cm)

Tips

For outdoor installations, use weatherproof connectors and seal all connections against moisture. Avoid exceeding the minimum bend radius to prevent performance degradation.
