DIGITUS Patch Panel CAT6A, blindado, 12 portas campo de identificação, 1U, montagem em rack de 10", preto RAL 9005

DIGITUS Patch Panel CAT6A, blindado, 12 portas campo de identificação, 1U, montagem em rack de 10
DIGITUS Patch Panel CAT6A, blindado, 12 portas campo de identificação, 1U, montagem em rack de 10
DIGITUS Patch Panel CAT6A, blindado, 12 portas campo de identificação, 1U, montagem em rack de 10
DIGITUS Patch Panel CAT6A, blindado, 12 portas campo de identificação, 1U, montagem em rack de 10
DIGITUS Patch Panel CAT6A, blindado, 12 portas campo de identificação, 1U, montagem em rack de 10
DIGITUS Patch Panel CAT6A, blindado, 12 portas campo de identificação, 1U, montagem em rack de 10
DIGITUS Patch Panel CAT6A, blindado, 12 portas campo de identificação, 1U, montagem em rack de 10
DIGITUS Patch Panel CAT6A, blindado, 12 portas campo de identificação, 1U, montagem em rack de 10
DIGITUS Patch Panel CAT6A, blindado, 12 portas campo de identificação, 1U, montagem em rack de 10
DIGITUS Patch Panel CAT6A, blindado, 12 portas campo de identificação, 1U, montagem em rack de 10
DIGITUS Patch Panel CAT6A, blindado, 12 portas campo de identificação, 1U, montagem em rack de 10
DIGITUS Patch Panel CAT6A, blindado, 12 portas campo de identificação, 1U, montagem em rack de 10", preto RAL 9005
34,76 €
Future-orientated standards and high-end quality for your network.- Sturdy patch panel with metal housing- Complete shielding of housing and shield contact- Cable installation by IDC-strips- Central grounding connector- Dielectric strength up to 1500 VDC (contact/ground)The CAT 6A patch panel is ava... Ler mais
Stock 4 Código 116897 Marca DIGITUS Modelo DN-91612S-EA Garantia 2 anos

Envios e devoluções

Entrega prevista Quinta-feira, Outubro 29
Receberá atualizações através do nosso sistema de seguimento detalhado
Opções de pagamento
Cartão bancárioVisaMastercardPayPalApple PayGoogle PayTransferência bancária

Future-orientated standards and high-end quality for your network.

- Sturdy patch panel with metal housing
- Complete shielding of housing and shield contact
- Cable installation by IDC-strips
- Central grounding connector
- Dielectric strength up to 1500 VDC (contact/ground)

The CAT 6A patch panel is available in this 12 port version. It offers sturdy design by its 1.5mm galvanic cold rolled steel. Perfect for 10" cabinet mounting. The fully shielded RJ45 sockets provide an optimal stability for your cables with best performances. The patch panel applies to (IEEE 802.3at/af) PoE+ standard. It is shielded electromagnetically and offers lost and interruption free forwarding of your data in your network. The 360 degree shielding at the contact points makes sure every single point of consilidation is shielded perfectly.

Destaques principais
  • Transmission properties: Category 6A, Class EA
  • Area of application: Up to 500 MHz, 10GBase-T
  • Norms: ISO/IEC 11801 2nd Ed., EN 50173-1, EIA/TIA 568-C, 802.3af, 802.3at PoE+
  • Suitable for surface mount installation
  • RJ45 female, 12P12C
  • Cable installation by IDC
  • Cable fixing with cable ties
  • Central ground connection
  • 360° shield coverage
  • Housing material: 1.5 mm galvanic cold rolled steel, acc. to EN1.4301, UNS S30400, AISI 304 and LMSAD110
  • RJ45 female material: ABS UL 94V-0
  • RJ45 female contact: Tinned phosphor bronze, 0.5 μ gold-plated contact
  • RJ45 shielding: Tinned bronze
  • IDC termination clamp: Krone IDC+, UL 94V-2, zinc plated phosphor bronze
  • Conductor plate: FR4, UL 94V-0
  • Insertion force: 30N max. (IEC 60603-7-5)
  • Retention strength: 7.7 kg between jack and plug
  • Operation temperature: -20° C to +70 °C (ISO/IEC 11801, EN 50173-1, ANSI/TIA/EIA 568 C)
  • Mating cycles female: > 750 acc. to ISO/IEC 11801, IEC 60603-7-5
  • Clamp: > 200 acc. to ISO/IEC 11801, IEC 60603-7-5
  • IDC wire size: 22 – 26 AWG solid and stranded conductor
  • Insulation resistance: > 500 MOhm
  • Contact resistance: < 20 MilliOhm
  • Dielectric strength: 1000 VDC (Contact/Contact), 1500 VDC (Contact/Ground)
  • Ground wire: Not included
Especificações
Bitola do fio (AWG)
22/26
Capacidade do rack
1U
Código da pauta aduaneira do Reino Unido
85369010
Código do Sistema Harmonizado (HS)
85371098
Conectores
RJ-45
Cor do produto
Black
Largura da embalagem
60 mm
Material
Metal
Montagem
Rack mounting
Número de portas
12
País de origem
China
Peso da embalagem
890 g
Profundidade da embalagem
260 mm
Tipo de interface Ethernet
10 Gigabit Ethernet
Tipos de cabos suportados
Cat6a
Volume da embalagem
1872 cm³

Folheto

Abrir documento
Histórico de preços nos últimos 6 meses
DIGITUS Patch Panel CAT6A, blindado, 12 portas campo de identificação, 1U, montagem em rack de 10", preto RAL 9005
Atual
34,76 €
Mais baixo
33,98 €
Mais alto
41,42 €
Variação 24 h
+0,77 €   +2%
Semana
+0,43 €   +1%
Mês
-0,39 €   -1%
