Distribuidor de zonas para rack Omnitronic ZD-160 – 16 canais, 1HE

Omnitronic ZD-160 — 16-channel, 1U rackmount zone distributor is a compact audio routing unit intended for professional installations. The device places 16 independently switchable outputs in a single 1U rack enclosure, enabling centralized distribution of line-level audio signals to multiple zones. It is designed for commercial audio systems where space efficiency, clear routing and reliable passive distribution are required, such as retail, hospitality, offices and public buildings.

Advantages

The 1U rack design saves rack space while providing a high channel count for zoned audio distribution. Front-panel controls allow quick, direct access to individual outputs. The unit delivers straightforward routing of line-level sources to multiple destinations without complex configuration. Its build is intended for installation use, simplifying wiring and centralizing zone management in one accessible location.

Suitable for

Key specifications

How to use

Install the ZD-160 in a standard 19-inch equipment rack using the supplied mounting hardware. Connect a line-level source (mixer, media player, paging processor) to the unit's input and run individual output lines to the amplifiers or powered speakers in each zone. Use the front-panel switches to enable or disable each of the 16 outputs as required. Confirm input/output signal levels at the source and destination to avoid clipping or noise, and secure wiring to prevent accidental disconnection during operation.

Recommendations

For reliable operation, place the unit in a ventilated rack space and maintain proper grounding between source equipment and connected amplifiers. Use balanced connections where possible to reduce interference on long cable runs, and label output cables for easier maintenance and zone identification.
