DOEPKE DLS 6H B13-3 Disjuntor de proteção de linha 3 polos 13A 6kA 09914112

Electrical circuits need reliable protection against overloads and short circuits, especially in residential and commercial installations. The DOEPKE DLS 6H B13-3 is a 3-pole miniature circuit breaker (MCB) engineered to safeguard cables and connected equipment. With a rated current of 13 A and a breaking capacity of 6 kA, it trips quickly on fault currents, preventing damage and fire hazards. Its B tripping characteristic makes it ideal for circuits with moderate inrush currents, such as lighting and socket outlets.

Who is it for

This MCB is intended for electricians, panel builders, and facility managers who need dependable circuit protection in distribution boards. It suits residential, commercial, and light industrial applications where three-phase circuits require coordinated overload and short-circuit protection.

Main features

• 3-pole design for three-phase circuits
• B tripping characteristic: magnetic trip between 3 and 5 times rated current
• Rated current 13 A, suitable for lighting and general-purpose circuits
• Breaking capacity 6 kA according to EN 60898-1
• Energy limiting class 3 for excellent current limitation
• DIN rail mounting (EN 60715) for quick installation
• Wide terminal capacity: 1.5–35 mm² solid, 1.5–25 mm² flexible
• High mechanical endurance: 20,000 operations

Specifications

• Product type: Miniature circuit breaker (MCB)
• Series: DLS 6H
• Number of poles: 3
• Tripping characteristic: B
• Rated current (In): 13 A
• Rated short-circuit breaking capacity (Icn): 6 kA
• Rated voltage (Un): 230/400 V AC
• Frequency: 50/60 Hz
• Energy limiting class: 3
• Mounting type: DIN rail (EN 60715)
• Terminal capacity (solid): 1.5–35 mm²
• Terminal capacity (flexible): 1.5–25 mm²
• Degree of protection (terminals): IP20
• Degree of protection (installed): IP40
• Operating temperature range: -25 °C to +50 °C
• Standard: EN 60898-1
• Overvoltage category: III
• Pollution degree: 2
• Mechanical endurance: 20,000 operations
• Electrical endurance: 10,000 operations

Tips

For optimal protection, coordinate this MCB with upstream devices to ensure selectivity. Use appropriate cable sizes based on the 13 A rating and installation conditions. Regularly test the breaker by pressing the test button if equipped, and ensure the distribution board provides adequate ventilation to maintain operating temperature within limits.
