EATON Conjunto de divisórias ZSD-SHT H 950/1100mm (113050)

For panel builders and enclosure integrators working with Rittal TS 8 enclosures, the EATON ZSD-SHT partitioning kit provides a clean separation between front and rear enclosure areas. This internal partition is essential when you need to create distinct climate zones, direct airflow for optimized thermal management, or add a fire protection barrier inside the cabinet.

Key specifications

• Product type: Partitioning kit
• Application: Internal enclosure separation
• Compatibility: Rittal TS 8 enclosures
• Enclosure height compatibility: 950 mm, 1100 mm
• Material: Sheet steel
• Surface finish: Zinc-plated
• Installation type: Internal mounting
• Included components: Assembly parts

Why choose it

The zinc-plated sheet steel construction ensures durability and corrosion resistance, while the modular design integrates seamlessly with the Rittal TS 8 system. By partitioning the enclosure, you can prevent hot air recirculation, improve cooling efficiency, and protect sensitive components from heat generated in adjacent sections.

Ideal use cases

• Separating power and control sections within a single enclosure
• Creating dedicated climate zones for high-heat components
• Enhancing fire protection by compartmentalizing the cabinet
• Optimizing airflow in enclosures with active cooling

Good to know

The kit includes all necessary assembly parts for internal mounting between the mounting angles or frame of the enclosure. It is designed for enclosures with a height of 950 mm or 1100 mm, matching standard Rittal TS 8 dimensions.
