Eaton M22S-WRLK-W Elemento frontal de interruptor basculante, Branco, com retenção, iluminado, 22,5 mm 216824

The Eaton M22S-WRLK-W is a front-mounted rocker switch element from the Moeller M22 series, distinguished by its illuminated white actuator and latching ON-OFF action. Unlike standard non-illuminated rockers, this unit integrates a white illumination window, providing clear status indication in control panels, machinery, and industrial enclosures. Its 22.5 mm mounting diameter ensures compatibility with standard industrial cut-outs, while the robust high-grade plastic construction supports demanding environments.

Highlights

• White illuminated rocker actuator for clear visual feedback
• Latching (maintained) 2-position ON-OFF switching function
• Designed for 22.5 mm panel mounting holes
• High mechanical durability exceeding 5 million operations
• Compatible with Eaton M22 contact blocks and LED elements

In daily use

This front element is the user-facing part of a modular pushbutton system. It mounts directly onto a panel and accepts separate M22 contact blocks and LED elements (not included) to complete the switching circuit and illumination. The white actuator colour provides high contrast against dark panels, and the latching action means the switch stays in the selected position until manually toggled. It is suitable for applications where a maintained ON-OFF control is required, such as machine start/stop, lighting control, or mode selection.

Full specifications

• Product Type: Rocker Switch Front Element
• Brand Series: Eaton Moeller M22
• Actuator Type: Rocker
• Switching Action: Latching (Maintained)
• Number of Positions: 2-Position
• Switching Function: ON-OFF
• Illumination: Yes
• Illumination Color: White
• Actuator Color: White
• Mounting Hole Diameter: 22.5 mm
• Front Protection Rating: IP66, IP67, IP69K
• Operating Temperature Range: -25 to +70 °C
• Material: High-grade Plastic
• Standards & Approvals: IEC/EN 60947, UL, CSA
• Compatibility: Requires M22 contact blocks and M22 LED elements
• Mechanical Durability: > 5 Million Operations
• Electrical Durability: > 0.5 Million Operations

Final note

For a complete switch assembly, pair this front element with Eaton M22 contact blocks and an M22 LED element of your choice.
