Eaton Minicontactor Z-S230/S 2NO 230V AC 20A calha DIN 265262

The Eaton Z-S230/S is a 2-pole mini contactor engineered for reliable switching of AC loads up to 20 A (AC-1) or 9 A (AC-3) at 400 V. Its 230 V AC coil and screw terminals make it a practical choice for control circuits in industrial and building automation.

Advantages

With a mechanical life of 10 million operations and electrical endurance of 1.5 million cycles (AC-3), this contactor delivers long-term dependability. DIN rail mounting simplifies installation in distribution boards and control panels. The IP20 housing protects against solid objects larger than 12 mm, suitable for indoor use.

Suitable for

• Switching motors up to 4 kW (AC-3, 400 V)
• Control of resistive loads such as heaters and lighting
• Integration into compact control systems with limited space
• Applications requiring frequent switching with high reliability

Key specifications

• Number of poles: 2
• Contact configuration: 2 NO (normally open)
• Coil voltage: 230 V AC
• Rated operational current: 20 A (AC-1), 9 A (AC-3) at 400 V
• Rated insulation voltage: 690 V
• Rated impulse withstand voltage: 6 kV
• Mounting: DIN rail
• Terminal type: screw terminals
• Degree of protection: IP20
• Operating temperature: -25 to +50 °C

Recommendations

For optimal performance, pair with a suitable motor protection circuit breaker and ensure proper tightening torque on screw terminals. Verify coil voltage compatibility before installation.
