Ficha de rede tipo F Bachmann 910.470

The Bachmann 910.470 Type F electrical power plug is a compact, durable plug designed for mains connections up to 16 A and 250 V AC. It features a plastic housing with integrated strain relief and is compatible with H05VV-F 3G 1.0 mm² cable. The brown colour and compact construction make it suitable for residential and office installations where a reliable, space-saving plug is required.

Advantages

The design uses robust plastic that resists impact and wear, while the integrated strain relief reduces cable stress at the entry point. The plug supports common household and office current ratings (16 A, 250 V AC) and accepts H05VV-F 3G 1.0 mm² cable, ensuring straightforward installation and long service life.

Suitable for

• Powering appliances and equipment in homes
• Office equipment and temporary power connections
• Replacement of damaged Type F plugs on compatible H05VV-F 3G 1.0 mm² cables

Key specifications

• Manufacturer: Bachmann
• Model / MPN: 910.470
• EAN: 4016514005451
• Type: Type F (Schuko) power plug
• Maximum current: 16 A
• Rated voltage: 250 V AC
• Cable compatibility: H05VV-F 3G 1.0 mm²
• Housing material: plastic
• Colour: brown

How to use

Ensure the mains supply is switched off before beginning installation. Prepare an H05VV-F 3G 1.0 mm² cable by stripping the outer sheath and exposing the conductors to the length specified by the plug manufacturer. Insert the conductors into the corresponding terminals following the plug’s markings for live, neutral and earth, then secure the strain relief clamp to prevent cable movement. Tighten terminal screws to the recommended torque and perform a continuity and polarity check before connecting to the supply.

Recommendations

Use this plug only with compatible H05VV-F 3G 1.0 mm² cable and within rated limits (16 A, 250 V AC). Do not modify the plug or use it with damaged cables. Installation should follow local electrical regulations; if unsure, have a qualified electrician carry out the installation and testing.
