Ficha RJ45 ShiverPeaks 08-45006 Cat. 8.1 sem ferramentas rápido STP para cabos Ethernet

The ShiverPeaks RJ45 connector 08-45006 Cat. 8.1 toolless quick STP is a shielded modular plug designed for fast field termination of compatible shielded Ethernet cables. It supports Category 8.1 performance for high-speed data networks and provides a secure shielded connection without the need for crimping tools. The connector is intended for installations where maintaining cable shielding and achieving reliable high-frequency performance are required, such as data centers, server rooms and structured cabling environments.

Advantages

This shielded RJ45 connector offers toolless, rapid termination that reduces installation time while preserving the cable shield continuity through an integrated metal housing. Its design supports Cat 8.1 frequency characteristics and high data rates, while the toolless mechanism simplifies on-site assembly and minimizes the need for specialized equipment. The connector's construction ensures consistent contact alignment and mechanical stability for repeated plug/unplug cycles.

Suitable for

• High-speed Ethernet links in data centers and server rooms
• Shielded structured cabling installations requiring STP terminations
• Field termination when quick, tool-free connections are preferred
• Short-run patch cables and bespoke cable assemblies that must retain shielding

Key specifications

• Category performance: Category 8.1 compatible
• Shielding: shielded (metal housing) to maintain cable screen continuity
• Termination type: toolless, quick assembly for stranded or solid compatible conductors (check cable compatibility)
• Contact arrangement: 8-position, 8-contact modular RJ45
• Use environment: suitable for structured cabling, server rooms and data center patching

How to use

Strip the cable jacket and prepare the individual pairs according to the connector manufacturer's recommended length. Ensure the cable drain wire and braid are accessible to guarantee shield continuity. Insert the prepared conductors into the connector in the correct order and push until they seat fully; engage the toolless locking mechanism to secure the conductors and the shield. Verify proper seating and test the terminated connection with appropriate network or certification testers to confirm electrical performance.

Recommendations

Use this connector with cables rated for Category 8.1 or compatible shielded cables and follow the cable manufacturer's prep guidelines to maintain shielding and performance. Test each terminated link with a suitable tester to validate continuity, pair integrity and shielding. Avoid excessive bending or tension at the termination point and ensure the connector's metal housing makes reliable contact with the cable braid or foil for optimal EMI protection.
