Finder 22.34.0.048.4720 Contator modular, 4 polos, bobina 48 V AC, 25 A, 3NO+1NC, calha DIN

Control lighting, heating, or motor loads in distribution boards and industrial control panels with the Finder 22.34.0.048.4720 modular contactor. This 2-module-wide device mounts on a 35 mm DIN rail and provides three normally open contacts plus one normally closed contact, all rated for 25 A resistive load. The 48 V AC coil operates at 50/60 Hz, making it suitable for building automation and machinery control circuits.

Key specifications

• Coil voltage: 48 V AC
• Contact configuration: 3 NO + 1 NC
• Rated current (AC-1): 25 A
• Rated operational voltage: 400 V AC
• Mounting: DIN rail 35 mm
• Module width: 2 modules (35 mm)

Why choose it

The compact design saves space in enclosures, while the mixed contact arrangement allows both switching and signaling functions in one unit. The 48 V AC coil is a common control voltage in industrial installations, and the contactor meets EN 61095 standards for household and similar fixed electrical installations.

Ideal use cases

• Switching lighting circuits in commercial buildings
• Controlling small motors up to 2.2 kW (AC-3)
• Interfacing with PLCs or timers for automation

Good to know

The contactor has an electrical life of 100,000 cycles at AC-1 and a mechanical life of 1,000,000 cycles. Operating temperature range is -25 to +55 °C. Terminals are IP20 protected, front panel IP40.
