Finder 7E.85.8.400.0310 Contador de energia digital monofásico, ligação direta, classe B, saída de impulso S0, calha DIN

With a maximum current of 40 A and Class B accuracy, this single-phase energy meter delivers precise active energy measurement in a compact 1-module DIN rail format.

Overview

The Finder 7E.85.8.400.0310 is a digital energy meter for direct connection in single-phase networks. It measures active energy (kWh) and provides an S0 pulse output for remote reading. The backlit LCD shows energy consumption with 6+1 digits, up to 999999.9 kWh.

What stands out

• MID certified (Module B + D) for billing applications
• Pulse output 1000 imp/kWh for integration with energy management systems
• Wide operating temperature range from -25 to +55 °C
• Front protection IP51, terminals IP20

Technical details

• Nominal voltage: 230 V AC
• Frequency: 50/60 Hz
• Basic current: 5 A, maximum current: 40 A
• Accuracy class: B (EN 50470-3)
• Display: LCD with backlight, 6+1 digits
• Communication: S0 pulse output, 1000 imp/kWh
• Mounting: DIN rail (EN 60715), 1 module (17.5 mm)
• Max cable cross-section: 16 mm²

Our verdict

A reliable and accurate energy meter for sub-billing and consumption monitoring in residential and commercial installations.
