Finder mini contactor 5,5kW bobina 24V DC 4 NO (6K.04.9.024.4312)

Mini contactor with 4 normally open main contacts, switching motors up to 5.5 kW at 400 V AC-3. The 24 V DC coil consumes only 2.5 W, making it suitable for energy-conscious control circuits.

Advantages

Compact 4-pole design fits 35 mm DIN rail or screw mounting. Rated insulation voltage 690 V and impulse withstand 6 kV ensure reliable operation in industrial environments. Long mechanical life of 10 million operations reduces maintenance.

Suitable for

• Motor starting and stopping in small machines
• Heating and lighting loads up to 20 A AC-1
• Control panels with 24 V DC logic

Key specifications

• Rated operational power: 5.5 kW (AC-3, 400 V)
• Rated operational current: 12 A (AC-3), 20 A (AC-1)
• Coil voltage: 24 V DC, consumption 2.5 W
• Number of poles: 4 NO
• Mounting: 35 mm DIN rail or screw
• Electrical life: 1,000,000 operations (AC-3)
• Mechanical life: 10,000,000 operations
• Operating temperature: -25 to +60 °C

Recommendations

Use with 24 V DC control systems for reliable switching of small motors and resistive loads. Verify coil polarity for DC operation.
