Fonte de alimentação MEAN WELL HDR-30-15

The MEAN WELL HDR-30-15 is an ultra-slim AC-DC DIN-rail power supply that delivers 15VDC at 2A with a total output power of 30W. It accepts a wide input voltage range of 85–264VAC and is designed for compact installations where space is limited. The unit meets RoHS requirements and is supplied in packs of 96 units for bulk applications.

Advantages

The HDR-30-15 offers a compact form factor (35mm x 54.5mm x 90mm) suitable for DIN-rail mounting, stable regulated 15V output, and universal AC input for use in varied mains environments. Its slim design and compliance with RoHS support integration in space-constrained electrical panels and environmentally conscious installations.

Suitable for

• Industrial control cabinets and automation systems
• Signal and communication equipment requiring 15VDC
• Compact embedded systems and small machines
• Bulk procurement for installation projects

Key specifications

• Model: MEAN WELL HDR-30-15 (MPN: HDR-30-15)
• Input voltage: 85–264VAC
• Output: 15VDC, 2A (30W)
• Dimensions: 35mm x 54.5mm x 90mm
• Mounting: DIN rail
• Compliance: RoHS
• Pack quantity: 96 units

How to use

Mount the HDR-30-15 on a standard DIN rail inside the control cabinet. Connect the AC mains to the input terminals observing proper grounding and polarity where applicable. Connect the 15VDC output to the load, ensuring the total current draw does not exceed 2A. Allow for adequate ventilation around the unit and follow local wiring regulations during installation.

Recommendations

For reliable operation, avoid overloading beyond the rated 2A output, install the unit in a ventilated enclosure away from heat sources, and ensure secure terminal connections. Use in environments within the specified input voltage range and consult MEAN WELL documentation for detailed installation and safety instructions.
