Cabo plano BVV-P 2x2,5 mm², dois condutores, isolado a PVC, cobre, branco, rolo de 50 m

Electricians wiring residential or commercial spaces often need a dependable flat cable that lies neatly against walls and ceilings. This BVV-P cable offers exactly that: two solid copper conductors, each 2.5 mm², encased in a white PVC sheath. The flat profile makes it easy to run under plaster, along skirting boards, or inside conduits, while the 50-metre roll provides enough length for multiple lighting or socket circuits.

Key specifications

• Cable type: BVV-P (flat twin, PVC insulated and sheathed)
• Number of cores: 2
• Conductor cross-section: 2.5 mm²
• Conductor material: Copper
• Insulation and sheath material: PVC
• Rated voltage: 300/500 V
• Maximum current rating (fixed installation): 25 A
• Operating temperature range: -30°C to +70°C
• Length: 50 m
• Colour: White
• Approximate outer dimensions: 4.5 x 8.5 mm
• Flame retardant (self-extinguishing)
• Compliance: GOST 31996-2012 or equivalent regional standard

Why choose it

This cable is built for permanent fixed wiring in dry or damp environments. The PVC insulation provides good electrical insulation and mechanical protection, while the white sheath blends discreetly into light-coloured interiors. Its flat shape reduces the risk of twisting and makes it easier to handle during installation. The 2.5 mm² copper conductors can safely carry up to 25 A, making the cable suitable for power circuits, lighting, and appliance connections.

Ideal use cases

• Fixed wiring for power and lighting circuits in residential buildings
• Concealed installation under plaster or in conduits
• Wiring for sockets, switches, and fixed appliances
• Commercial spaces requiring neat, surface-mounted cable runs

Good to know

The cable is not UV resistant and not halogen-free, so it is intended for indoor use where it is not exposed to direct sunlight. Always ensure installation complies with local electrical codes and is performed by a qualified electrician.
