Getfort Painel de Distribuição de Energia 3U 22x Schuko 230V 16A Cabo 2m Preto

The Getfort 3U 22x Schuko Power Distribution Panel is a robust 19-inch rackmount PDU designed for professional server rooms and network cabinets. With 22 Schuko (CEE 7/3) outlets and a 2-meter input cable with Schuko plug, it provides reliable power distribution for up to 22 devices. Rated at 230V AC, 16A maximum current, and 3680W maximum power, it features an illuminated ON/OFF switch and overload circuit breaker for safety. The aluminum housing in black ensures durability and efficient heat dissipation.

Advantages

• 22 Schuko outlets in a compact 3U form factor maximize rack space utilization.
• Integrated overload circuit breaker protects connected equipment from current surges.
• Illuminated ON/OFF switch provides clear visual status and easy power control.
• Aluminum construction offers lightweight strength and corrosion resistance.
• Horizontal 19-inch rackmount design fits standard server racks seamlessly.

Suitable for

• Data centers and server rooms requiring multiple Schuko power outlets.
• Network cabinets with 19-inch racks needing organized power distribution.
• IT professionals deploying servers, switches, and other rack-mounted equipment.
• Audio/visual installations where reliable power distribution is critical.

Key specifications

• Rack Unit Height: 3U
• Number of Outlets: 22
• Outlet Type: Schuko (CEE 7/3)
• Input Connector: Schuko (CEE 7/7) Plug
• Input Cable Length: 2 m
• Nominal Voltage: 230V AC
• Maximum Current: 16 A
• Maximum Power: 3680 W
• Mounting: 19-inch Rackmount
• Housing Material: Aluminum
• Color: Black
• Protection: Overload Circuit Breaker
• Control: Illuminated ON/OFF Switch
• Orientation: Horizontal
• Frequency: 50/60 Hz
• Cable Specification: H05VV-F 3G1.5mm²
• Certifications: CE, RoHS

Recommendations

For optimal performance, ensure the total connected load does not exceed 3680W. Use with a dedicated 16A circuit breaker. Suitable for indoor use only.
