GIGABYTE R283-S93-AAF1 servidor rackmount 2U, Intel Xeon 5.ª/4.ª geração, 12x baías hot-swap de 3,5 polegadas/2,5 polegadas, 2x fontes de alimentação redundantes 2400W

The GIGABYTE R283-S93-AAF1 is a high-performance 2U rackmount server designed for demanding data center and enterprise workloads. Powered by dual Intel Xeon E5-2600 v3/v4 processors and the Intel C612 chipset, it delivers exceptional compute power and reliability. With 24 DDR4 DIMM slots supporting up to 1.5TB of LRDIMM memory, this server handles virtualization, database, and HPC applications with ease.

Advantages

Optimized for scalability and efficiency, the R283-S93-AAF1 features 12 front hot-swap drive bays (3.5"/2.5") with SAS/SATA support via an LSI SAS3008 controller, plus 2 rear 2.5" SATA bays. Dual 2400W 80 PLUS Platinum redundant power supplies ensure high availability and energy savings. The server includes 8 PCIe Gen3 x16 slots for expansion, dual 1GbE LAN, and dedicated IPMI 2.0 management.

Suitable for

• Enterprise data centers requiring high-density storage and compute
• Virtualization environments (VMware, Hyper-V)
• Database servers and business-critical applications
• High-performance computing (HPC) clusters

Key specifications

• Form Factor: 2U Rackmount
• Processor: 2x Intel Xeon E5-2600 v3/v4
• Chipset: Intel C612
• Memory: 24x DDR4 DIMM, up to 1.5TB LRDIMM
• Storage: 12x 3.5"/2.5" hot-swap SAS/SATA (front) + 2x 2.5" SATA (rear)
• RAID: LSI SAS3008 (12Gb/s)
• Expansion: 8x PCIe Gen3 x16
• Network: 2x 1GbE LAN (Intel I350-AM2)
• Management: 1x dedicated IPMI 2.0 LAN
• Power: 2x 2400W 80 PLUS Platinum redundant
• Cooling: 6x hot-swappable system fans

Recommendations

For optimal performance, pair with Intel Xeon E5-2600 v4 processors and high-speed DDR4 ECC memory. This server is ideal for mission-critical deployments requiring maximum uptime and scalability.
