Gira System 55 mecanismo de interruptor de balancim 2 polos OFF, branco puro mate 283403

Electricians and installers use this Gira System 55 rocker switch insert to control lighting circuits in residential and commercial buildings. It is a 2-pole OFF switch rated for 250 V AC and 10 A, designed for flush-mounted installation in standard wall boxes. The insert is part of the Gira System 55 modular range and pairs with compatible frames and rocker covers (sold separately).

Key specifications

• Switching function: OFF switch (2-pole)
• Rated voltage: 250 V AC
• Rated current: 10 A
• Mounting type: Flush-mounted
• Connection type: Screw terminals
• Material: Thermoplastic
• Colour: Pure white matt
• Halogen-free: Yes
• Protection class: IP20
• Conductor cross-section: 1.5 - 2.5 mm²
• Installation depth: 32 mm
• Operating temperature: -5 to +40 °C

Why choose it

The switch insert is halogen-free and made of durable thermoplastic. Its screw terminals accept solid conductors from 1.5 to 2.5 mm², ensuring a secure connection. The pure white matt finish matches the Gira System 55 aesthetic and can be combined with various rocker designs.

Ideal use cases

• Switching lighting circuits in homes and offices
• Controlling electrical loads up to 10 A
• Flush-mounted installations with Gira System 55 frames

Good to know

The insert is not illuminated, but it can be retrofitted with a lamp if indication is required. It is designed for indoor use (IP20) and fits into standard flush-mounted boxes with a depth of at least 32 mm.
