Good Connections cabo de patch de fibra ótica duplex OM4 (multimodo 50/125) SC/ST - 7,5 m

The Good Connections LW-8075TC4 is a high-performance fiber optic patch cable designed for reliable data transmission in demanding network environments. With duplex OM4 multimode fiber, SC to ST connectors, and a length of 7.5 meters, this cable ensures low insertion loss and high bandwidth for 10 GbE and beyond.

Advantages

OM4 fiber supports higher data rates over longer distances compared to OM3. The LSZH jacket provides safety in confined spaces. Typical insertion loss ≤0.3 dB ensures signal integrity.

Suitable for

• Data centers
• Storage area networks (SAN)
• Local area networks (LAN)
• High-speed backbone connections

Key specifications

• Cable type: Fiber Optic Patch Cable
• Fiber mode: Multimode
• Fiber class: OM4
• Core/Cladding: 50/125 µm
• Number of fibers: 2 (Duplex)
• Connector A: SC
• Connector B: ST
• Length: 7.5 m
• Jacket color: Aqua
• Jacket material: LSZH
• Insertion loss (typical): ≤0.3 dB
• Return loss (typical): ≥30 dB
• Attenuation at 850 nm: ≤3.0 dB/km
• Attenuation at 1300 nm: ≤1.0 dB/km
• Modal bandwidth at 850 nm: 4700 MHz·km
• Modal bandwidth at 1300 nm: 500 MHz·km
• Operating temperature: -20°C to 70°C
• Standards: IEC 60793-2-10 Type A1a.3, TIA/EIA-492AAAD

Recommendations

For optimal performance, use with OM4-rated transceivers and ensure clean connector end-faces before installation.
