Grafenthal transceptor X140 40G QSFP+ LC LR4 SM 10KM 1310NM SMF

The Grafenthal TRANSCEIVER X140 is a high-performance 40 Gigabit Ethernet QSFP+ transceiver module designed for long-range single-mode fiber connections. It is fully compatible with HP/Aruba JG661A and delivers reliable, high-speed data transmission over distances up to 10 km.

Advantages

This transceiver offers exceptional performance with low power consumption (<3.5 W) and supports Digital Diagnostics Monitoring (DDM) for real-time performance tracking. Its hot-swappable design ensures minimal network downtime during installation or upgrades.

Suitable for

• Data center interconnects
• Enterprise networking
• Campus networks
• 40GBASE-LR4 compliant applications

Key specifications

• Form Factor: QSFP+
• Data Rate: 40 Gbps
• Wavelength: 1310 nm
• Max Distance: 10 km
• Fiber Type: Single-Mode Fiber (SMF)
• Connector Type: LC Duplex
• Optical Technology: LR4
• Standards Compliance: IEEE 802.3ba 40GBASE-LR4
• Hot-Swappable: Yes
• DDM: Yes
• Power Consumption: <3.5 W
• Operating Temperature: 0°C to 70°C
• Storage Temperature: -40°C to 85°C
• Humidity (Operating): 0% to 85% (non-condensing)
• Compatibility: HP/Aruba JG661A equivalent

Recommendations

For optimal performance, pair this transceiver with high-quality single-mode fiber patch cables and ensure proper cleaning of all optical connectors before installation.
