Grafenthal transceptor X140 40G QSFP+ MPO SR4 100M 850NM MMF

The Grafenthal TRANSCEIVER X140 is a high-performance 40 Gigabit Ethernet QSFP+ transceiver designed for reliable data transmission over multimode fiber. It is fully compatible with HPE X140 40G QSFP+ MPO SR4 (JG325B) and offers exceptional performance for data center and enterprise networking applications.

Advantages

This transceiver delivers high-speed connectivity with low power consumption (<1.5W) and supports Digital Optical Monitoring (DOM) for real-time performance tracking. Its hot-swappable design ensures minimal downtime during maintenance or upgrades.

Suitable for

• Data center interconnects
• Enterprise networking
• High-performance computing (HPC)
• 40GBASE-SR4 compliant networks

Key specifications

• Transceiver Type: QSFP+
• Data Rate: 40 Gigabit Ethernet (40GbE)
• Wavelength: 850 nm
• Max Distance: 100 m over OM3/OM4 MMF
• Fiber Type: Multimode Fiber (MMF)
• Connector Type: MPO/MTP-12 (Female)
• Form Factor: QSFP+ (Quad Small Form-Factor Pluggable Plus)
• Standard: IEEE 802.3ba 40GBASE-SR4
• Digital Optical Monitoring (DOM): Yes
• Hot-Swappable: Yes
• Power Consumption: < 1.5 W
• Operating Temperature: 0°C to 70°C (32°F to 158°F)
• Compatibility: HPE X140 40G QSFP+ MPO SR4 (JG325B equivalent)
• Channels: 4 Transmit (Tx) and 4 Receive (Rx)
• Media Type: Optical Fiber
• Protocol: Ethernet
• Optical Components: VCSEL laser, PIN photo-detector
• Certifications: CE, FCC, RoHS, MSA Compliant

Recommendations

For optimal performance, use with OM3 or OM4 multimode fiber cables. Ensure compatibility with your network equipment before installation.
