Guangzhou Shirui XCore Kit Pro placa de desenvolvimento FPGA com Xilinx Artix-7 A35T

The Guangzhou Shirui XCore Kit Pro is a high-performance FPGA development board built around the Xilinx Artix-7 A35T chipset. Designed for engineers, hobbyists, and students, it offers a rich set of peripherals including Gigabit Ethernet, HDMI, MIPI CSI-2 camera interface, and dual 40-pin GPIO headers. With 512MB DDR3 SDRAM and 128Mbit QSPI flash, it is ideal for prototyping digital circuits, embedded vision, and IoT applications.

Advantages

Powered by the Xilinx Artix-7 A35T FPGA with 33,280 logic cells and 90 DSP slices, the XCore Kit Pro delivers robust performance for complex designs. Its onboard JTAG via USB-C simplifies debugging, while the 50MHz crystal oscillator ensures stable clocking. The board supports Xilinx Vivado Design Suite, making it compatible with industry-standard tools.

Suitable for

• FPGA prototyping and education
• Digital signal processing (DSP) projects
• Embedded vision and camera systems
• High-speed data acquisition and control

Key specifications

• Main Chipset: Xilinx Artix-7 A35T FPGA
• Logic Cells: 33,280
• DSP Slices: 90
• Block RAM: 1,800 Kbits
• Onboard RAM: 512MB DDR3 SDRAM
• Onboard Flash: 128Mbit QSPI Flash
• USB Interface: 1x USB-C (Power, Data, UART)
• Network Interface: 1x Gigabit Ethernet (RJ45)
• Video Output: 1x HDMI 1.4
• Camera Interface: 1x MIPI CSI-2 (2-lane)
• GPIO Expansion: 2x 40-pin GPIO Headers (2.54mm pitch)
• PMOD Interfaces: 2x 12-pin PMOD Headers
• Debugging Interface: Onboard JTAG via USB-C
• Clock Source: 50MHz Crystal Oscillator
• Power Input: 5V DC via USB-C
• User Peripherals: 4x User LEDs, 2x User Buttons, 1x Reset Button
• Software Toolchain: Xilinx Vivado Design Suite
• Operating Temperature: 0°C to 70°C

Recommendations

For best results, use the Xilinx Vivado Design Suite for development. Ensure adequate cooling when operating at high logic utilization. Compatible with standard PMOD and 2.54mm pitch GPIO modules.
