Hager LFF6011057035 Curva plana 110x60 mm cinzento claro

For clean 90-degree direction changes in Hager tehalit.LFF cable trunking, this flat angle is made from PVC in pure white (RAL 9010). Designed for 110 x 60 mm profiles, it snaps on without tools and keeps cable routing tidy on flat surfaces.

Overview

The Hager LFF6011057035 is a flat angle fitting for the tehalit.LFF series. It allows the trunking to change direction horizontally while maintaining a neat appearance. The component is manufactured from polyvinyl chloride and finished in pure white, matching the trunking system.

What stands out

• Snap-on mounting for quick installation
• Matches 110 x 60 mm trunking profile
• Self-extinguishing PVC material
• RAL 9010 pure white finish

Technical details

• Product type: Flat angle
• System: Hager tehalit.LFF
• Trunking size: 110 x 60 mm
• Material: PVC
• Colour: Pure white (RAL 9010)
• Mounting: Snap-on
• Halogen-free: No
• UV resistant: No
• Temperature range: -5 to +60 °C
• Protection class: IP30
• Fire behaviour: Self-extinguishing
• Suitable for functional integrity: No
• Packaging unit: 1 piece

Our verdict

A straightforward flat angle that ensures your tehalit.LFF trunking turns corners neatly. The snap-on design saves time, and the pure white colour blends seamlessly with the rest of the system.
