HAGER WNA021 Botão iluminado com contacto comutador, série W.1, branco polar

The HAGER WNA021 stands out with its integrated LED illumination, making the switch easy to locate in dark hallways or staircases while adding a subtle visual indicator of its status. Unlike standard mechanical push-buttons, this model combines a momentary action with a changeover contact, offering flexible control for lighting circuits, doorbells, or pulse relays.

Highlights

• Integrated LED illumination for clear visibility and status indication
• Changeover (SPDT) contact supports versatile switching configurations
• Flush-mounted design fits standard wall boxes for a clean, seamless look
• Part of the Hager W.1 series, ensuring compatibility with matching cover plates and frames
• Halogen-free thermoplastic construction in polar white (RAL 9010) for durability and a neutral appearance

In daily use

Ideal for residential and commercial applications, the WNA021 provides a reliable momentary contact that returns to its rest position after actuation. The screw terminals accept rigid conductors from 1.5 to 2.5 mm², ensuring secure connections. Rated for 250 V AC and 10 A, it handles typical lighting loads with ease. The operating temperature range of -5 to +40 °C makes it suitable for most indoor environments.

Full specifications

• Switch type: Push-button (momentary)
• Contact configuration: Changeover (SPDT)
• Rated voltage: 250 V AC
• Rated current: 10 A
• Connection type: Screw terminals
• Mounting type: Flush-mounted
• Design line: Hager W.1
• Material: Halogen-free thermoplastic
• Colour: Polar White (RAL 9010)
• Number of rockers: 1
• Terminal capacity: 1.5 – 2.5 mm² rigid conductors
• Operating temperature: -5 to +40 °C

Final note

The WNA021 requires a Hager W.1 cover plate and frame for a complete installation, allowing you to match the surrounding décor while enjoying the benefits of illuminated control.
