HellermannTyton Base de fixação adesiva série MB para abraçadeiras, 19 x 19 mm, branco, PA66, 100 unid. (308-31807)

In control panels and network cabinets, cable ties need a secure anchor point without drilling. This adhesive mount from HellermannTyton's MB series provides a low-profile base for cable ties up to 3.6 mm wide. The 19 x 19 mm footprint holds to smooth surfaces with its synthetic rubber adhesive, keeping bundles tidy in indoor installations.

Key specifications

• Base dimensions: 19 x 19 mm
• Height: 4.3 mm
• Max. cable tie width: 3.6 mm
• Material: Polyamide 6.6 (PA66), white
• Adhesive: Synthetic rubber
• Operating temperature: -40 °C to +85 °C
• Flammability rating: UL94 V2
• Halogen-free
• Pack size: 100 pieces

Why choose it

The compact design keeps cable bundles close to the mounting surface, reducing snagging in tight spaces. PA66 offers strength and resistance to common indoor environments, while the adhesive backing speeds up installation compared to screw-mounted bases.

Ideal use cases

• Securing cables inside electrical enclosures
• Organizing wiring on smooth panels or desks
• Creating temporary cable routes in offices
• Prototyping cable layouts before permanent fixing

Good to know

For best adhesion, clean the surface before applying and allow the adhesive to cure. Not recommended for outdoor use due to lack of UV resistance.
