HellermannTyton Base de fixação para abraçadeiras Verde Polipropileno 55x35mm -20 a 90°C 1 unid.

The HellermannTyton Cable Tie Mounting Base is a reliable and durable solution for secure cable management. Made from high-quality polypropylene (PP), this mounting base offers excellent resistance to a wide range of temperatures and environmental conditions. Its compact dimensions of 55 mm length and 35 mm width make it ideal for various applications where space is limited.

Advantages

This mounting base provides a stable anchor point for cable ties, ensuring organized and secure cable routing. The polypropylene material is halogen-free and RoHS compliant, making it an environmentally friendly choice. With an operating temperature range of -20 to 90 °C, it performs reliably in both cold and warm environments. The UL94 HB flammability rating adds an extra layer of safety.

Suitable for

• Cable management in electrical cabinets and control panels
• Securing cables in automotive and industrial applications
• Home and office cable organization
• Any application requiring a fixed cable tie point

Key specifications

• Product Type: Cable Tie Mounting Base
• Material: Polypropylene (PP)
• Colour: Green
• Length: 55 mm
• Width: 35 mm
• Operating Temperature Range: -20 to 90 °C
• Mounting Method: Screw or Adhesive
• Max. Cable Tie Width: 8.0 mm
• Fixing Hole Diameter: 5.3 mm
• Flammability Rating: UL94 HB
• Halogen-free: Yes
• UV Resistant: No
• RoHS Compliant: Yes
• Unit Quantity: 1 piece

Recommendations

For best results, use with HellermannTyton cable ties of appropriate width. Ensure the mounting surface is clean and dry before installation. For screw mounting, use screws with a diameter suitable for the 5.3 mm fixing hole.
