HellermannTyton SBPEFR4 PEFR WH 30 Manga de Malha Auto-Fechável, Branca, 30 mm, Rolo de 25 m

Self-closing braided sleeving with a 30 mm nominal diameter, engineered for fast installation and high abrasion resistance. The open-weave polyester monofilament construction allows the sleeve to wrap around existing bundles without disconnecting cables or connectors.

Overview

The SBPEFR4 PEFR WH 30 is a white, self-closing braided sleeving supplied on a 25-metre roll. It accommodates bundle diameters from 25 mm to 35 mm and expands up to 1.5 times its nominal size for a snug fit. The polyester (PET) monofilament material delivers high abrasion resistance, good UV and chemical resistance, and operates from -50 °C to +150 °C. The sleeving is halogen-free and carries a UL94 V0 flame retardancy rating, making it suitable for applications where fire safety is a concern.

What stands out

• Self-closing design speeds installation and allows retrofitting without disassembly
• Wide temperature range: -50 °C to +150 °C
• UL94 V0 flame retardant and halogen-free
• High abrasion resistance for demanding environments
• 25-metre roll provides ample length for multiple projects

Technical details

• Product type: Self-closing braided sleeving
• Material: Polyester (PET) monofilament
• Colour: White
• Nominal diameter: 30 mm
• Bundle diameter range: 25–35 mm
• Length: 25 m
• Operating temperature: -50 °C to +150 °C
• Flame retardancy: UL94 V0
• Halogen-free: Yes
• Expansion ratio: up to 1:1.5
• Abrasion resistance: High
• UV resistance: Good
• Chemical resistance: Good against most common chemicals
• Standards compliance: RoHS, UL Recognized

Our verdict

A practical choice for cable management in automotive, industrial, and electronics applications where quick installation and reliable protection are required.
