Hikvision DS-220AZJ-145-BA Fonte de Alimentação 12V 1,5A 18W

The Hikvision DS-220AZJ-145-BA is a high-quality desktop power adapter designed to provide reliable 12V DC power to Hikvision security cameras, DVRs, NVRs, and other compatible 12V devices. With an output of 1.5A and 18W, this adapter ensures stable performance for your surveillance equipment. It features a 5.5mm x 2.1mm barrel jack with center positive polarity and a 1.2-meter DC output cable for flexible installation.

Advantages

This power adapter offers Level VI energy efficiency, reducing power consumption and heat generation. It includes multiple protection features such as Over-Voltage Protection (OVP), Over-Current Protection (OCP), and Short-Circuit Protection (SCP) to safeguard your connected devices. The compact desktop design and black ABS plastic enclosure make it durable and easy to integrate into any setup.

Suitable for

• Hikvision security cameras (e.g., DS-2CD series, DS-2CE series)
• Hikvision DVRs and NVRs
• Any 12V DC device requiring up to 1.5A current

Key specifications

• Input: AC 100-240V, 50/60 Hz
• Output: DC 12V, 1.5A, 18W
• Connector: 5.5mm x 2.1mm barrel jack, center positive
• AC input: IEC C8 (Figure 8)
• DC cable length: 1.2 meters
• Efficiency: Level VI
• Protection: OVP, OCP, SCP
• Operating temperature: -10°C to 40°C
• Certifications: CE, FCC, RoHS
• Color: Black
• Material: ABS plastic

Recommendations

For optimal performance, use only with compatible Hikvision devices. Ensure the total current draw does not exceed 1.5A. This adapter is not suitable for outdoor use without additional weatherproofing.
