Hikvision DS-KAW50-1N Fonte de Alimentação para Estação de Portão, 50W, 12VDC, 4,16A, Preto

The Hikvision DS-KAW50-1N is a high-performance AC/DC switching power adapter specifically designed for Hikvision IP Video Intercom Outdoor Stations. It provides a reliable 12VDC output with 4.16A current and 50W power, ensuring stable operation of gate stations even in demanding environments. With a wide input voltage range of 100-240VAC and robust protection features, this power supply is ideal for security and access control applications.

Advantages

Engineered for continuous operation, the DS-KAW50-1N offers overload, short circuit, over-voltage, and over-current protection. Its wall-mountable design saves space, and the LED indicator provides clear power status. The unit operates in extreme temperatures from -40°C to 70°C, making it suitable for outdoor installations.

Suitable for

• Hikvision IP Video Intercom Outdoor Stations (e.g., DS-KV8X13, DS-KV8X02, DS-KV6113 series)
• Gate station power supply needs
• Security and access control systems requiring reliable 12VDC power

Key specifications

• Input Voltage: 100-240 VAC, 50/60 Hz
• Output Voltage: 12 VDC
• Output Current: 4.16 A
• Output Power: 50 W
• Power Supply Type: AC/DC Switching Power Adapter
• Mounting Type: Wall-mounted
• Operating Temperature: -40°C to 70°C (-40°F to 158°F)
• Storage Temperature: -40°C to 85°C (-40°F to 185°F)
• Protection: Overload, Short Circuit, Over-voltage, Over-current
• LED Indicator: Yes, Power Status LED
• Enclosure Material: Plastic
• Input Connector: Screw Terminals
• Output Connector: Screw Terminals
• Humidity: 0% to 95% (non-condensing)
• Certifications: CE, FCC, RoHS

Recommendations

For optimal performance, use only with compatible Hikvision gate stations. Ensure proper ventilation and secure wall mounting. This power supply is a direct replacement for the original DS-KAW50-1N unit.
