Hikvision DS-XS10-P Switch de secretária 6 portas 4 portas PoE+

The Hikvision DS-XS10-P is a compact and reliable 6-port desktop switch designed for small to medium-sized network installations. With 4 PoE+ ports and a total PoE budget of 35 W, it provides power and data connectivity to IP cameras, access points, and other PoE devices. The switch supports IEEE 802.3af/at standards, ensuring compatibility with a wide range of equipment. Its store-and-forward switching architecture, 1.2 Gbps switching capacity, and 2K MAC address table deliver efficient data handling. The DS-XS10-P also features PoE watchdog and extend mode for enhanced reliability and long-distance transmission up to 250 meters at 10 Mbps.

Advantages

This switch offers a cost-effective solution for powering and connecting network devices without the need for separate power cables. Its compact desktop design and wall-mount capability make it easy to install in various environments. The PoE watchdog automatically resets non-responsive PoE devices, reducing downtime. Extend mode allows for flexible deployment in large areas.

Suitable for

• Small office and home office networks
• IP surveillance systems
• Wireless access point installations
• Retail and hospitality environments

Key specifications

• 6 ports: 4 PoE+ 10/100 Mbps RJ45 + 2 uplink 10/100 Mbps RJ45
• PoE standard: IEEE 802.3af/at
• PoE power budget: 35 W, up to 30 W per port
• Switching capacity: 1.2 Gbps
• Packet forwarding rate: 0.8928 Mpps
• MAC address table: 2K
• Jumbo frame support: 1536 bytes
• Transmission mode: Store-and-forward
• Power supply: 48 VDC, 0.8 A external adapter
• Max power consumption: ≤ 38 W (including PoE)
• Operating temperature: -10 °C to 55 °C (14 °F to 131 °F)
• Operating humidity: 5% to 95% RH, non-condensing
• Mounting: Desktop, wall-mount
• Surge protection: 6 KV for PoE ports

Recommendations

For optimal performance, use high-quality Cat5e or better Ethernet cables. Ensure the power adapter is connected to a stable power source. The switch is ideal for powering Hikvision IP cameras and other compatible devices.
