Hub de interface EXSYS EX-1132-N USB 3.2 Gen 1 Type-C

The EXSYS EX-1132-N Interface Hub expands a single USB 3.2 Gen 1 Type-C host connection into three USB 3.2 Gen 1 Type-A ports and one Gigabit RJ-45 Ethernet port. The compact white metal-cased hub supports data transfer rates up to 5000 Mbit/s over USB and provides a 10/100/1000 Mbps network connection through the RJ-45 port. It includes a short integrated cable (0.31 m) and an A-male to C-female adapter for use with standard USB-A host ports.

Advantages

The hub enables simultaneous connection of up to three external USB 2.0/3.0 devices to a single USB-C or USB-A host without requiring an external power supply. Gigabit Ethernet support offers a wired network option alongside USB expansion in one compact, metal enclosure. The device is plug-and-play compatible and can be used together with an existing network card.

Suitable for

• Connecting multiple USB peripherals (storage drives, keyboards, mice) to a laptop or desktop
• Adding a wired Gigabit Ethernet connection to notebooks without an RJ-45 port
• Small office or home setups where compact USB and network expansion is required

Key specifications

• Host interface: USB 3.2 Gen 1 (Type-C), compatible with USB 3.0/2.0
• Downstream ports: 3 × USB 3.2 Gen 1 Type-A
• Network: RJ-45 Gigabit Ethernet (10/100/1000 Mbps)
• Data transfer rate: up to 5000 Mbit/s (USB)
• Cable length: 0.31 m
• Dimensions: 122 × 55 × 28 mm
• Colour: White
• Weight: 0.3 kg

How to use

Connect the integrated USB-C cable or the included A-male to C-female adapter to the host computer’s USB-C or USB-A port. Plug USB devices into the Type-A ports and connect an Ethernet cable to the RJ-45 port for network access. The hub is designed for plug-and-play operation; drivers are typically installed automatically by the host operating system.

Recommendations

For stable network and peripheral performance, use quality Ethernet cables and avoid connecting high-power USB devices that may exceed the hub’s bus-powered capability. If multiple high-current devices are required, consider using externally powered USB hubs or devices with their own power supply.
