Icron Ranger 2324 extensor KVM transmissor e recetor (00-00412)

Extend USB 2.0 and DVI-D signals up to 100 meters over a single Cat5e/6/7 cable with the Icron Ranger 2324 KVM Extender. This sender and receiver pair delivers full keyboard, video, and mouse control at distances up to 330 feet, supporting resolutions up to 1920 x 1200 at 60Hz.

Overview

The Icron Ranger 2324 is a hardware-based KVM extender that transmits USB 2.0 (up to 480 Mbps) and DVI-D single-link video over standard Cat5e, Cat6, or Cat7 cabling. It is OS independent and plug-and-play, requiring no software drivers. The system includes a local extender (LEX) and a remote extender (REX), each with its own 5V DC power adapter.

What stands out

• 100 m (330 ft) extension over a single Cat5e/6/7 cable
• 4 USB 2.0 Type-A ports on the remote unit for peripherals
• Supports DVI-D video up to 1920 x 1200 @ 60Hz
• Plug-and-play, no software required
• Metal housing with ESD protection (8kV contact, 15kV air)

Technical details

• Extension technology: USB 2.0 and DVI-D over Cat5e/6/7
• Maximum transfer distance: 100 m
• USB standard: USB 2.0 (480 Mbps)
• Local USB port: 1 x USB 2.0 Type-B (host)
• Remote USB ports: 4 x USB 2.0 Type-A
• Video interface: DVI-D single link
• Maximum digital resolution: 1920 x 1200 @ 60Hz
• Required cable: Cat5e/6/7 (UTP or STP)
• Power: 2 x external 5V DC adapters (included)
• LED indicators: Power, Link, Host Status
• Mounting: Surface mountable
• Housing: Metal

Our verdict

A reliable, hardware-based KVM extension solution for industrial and commercial environments where USB and DVI signals must travel long distances over standard network cabling.
