IIYAMA ProLite LH9252UWS-B1AG ecrã de 92 polegadas 5120x2160 VA 60Hz

The IIYAMA ProLite LH9252UWS-B1AG is a 92" (232.5 cm) 5K UltraWide display featuring a VA panel with a matte, anti-glare coated glass surface and 25% haze. It is designed for collaborative workspaces, digital signage and immersive presentation environments, and includes an integrated Android 13 OS with iiyama DMS, iiyama Share and EShare.

Key features

• 92" (232.5 cm) 5K UltraWide VA panel with AG coated glass, matte surface, haze 25%
• Physical resolution 5120x2160 @60Hz (5K), aspect ratio 21:9
• Brightness 500 cd/m², contrast ratio 5000:1, dynamic contrast 5000:1
• Response time 6.5 ms, viewing angle 178/178° (right/left 89/89°, top/bottom 89/89°)
• Colour support 1.07G (8 bits+FRC), horizontal frequency 30-135KHz
• Integrated software: Android 13 OS, iiyama DMS, iiyama Share, EShare
• Wi-Fi: yes (WiFi 6E + BT 5.2)
• Hardware SOC: RK3588 Octo-core A76x4 + A55x4, GPU Mali G640 MP4, RAM 8GB, ROM 128GB
• Intel OPS 80pin slot, kiosk mode, max operating time 24/7
• Metal front frame, landscape and portrait orientation
• VESA 800 x 600 mm
• Speakers 2 x 20W (20W subwoofer)
• Blue light reduction, flicker-free LED, plug & play DDC2B
• OSD menu languages: EN, DE, FR, ES, IT, RU, CN, CZ, NL, PL, JP, CAT, FI, DA, ET, LV, LT, HU
• Operating temperature 0°C-40°C, storage temperature -20°C-60°C
• Power supply AC 100-240V, 50/60Hz, internal power supply
• Power consumption 201W typical, 0.5W standby, 0.3W off
• Regulations: CB, CE, TÜV-Bauart, EAC, RoHS Support, ErP, WEEE, REACH, UKCA
• Energy efficiency class G, REACH SVHC: contains lead over 0.1%
• Dimensions W x H x D: 2182 x 943.8 x 85.2 mm, weight 44 kg
• Included accessories: power cable (3m), HDMI cable (3m), DP cable (3m), RS-232c cable (3m), startup guide, safety notes, user manual, cable cover, remote control (batteries included), cable ties (5 pcs), webcam holder, wall mount, wall mount set

Specifications

• Brand: Iiyama
• MPN: LH9252UWS-B1AG
• Diagonal: 92" (233 cm)
• Panel technology: VA, AG coated glass, matte surface, haze 25%
• Physical resolution: 5120x2160 @60Hz (5K)
• Aspect ratio: 21:9
• Brightness: 500 cd/m²
• Contrast ratio: 5000:1
• Dynamic contrast: 5000:1
• Response time: 6.5 ms
• Viewing angle: horizontal/vertical 178/178°, right/left 89/89°, top/bottom 89/89°
• Colour support: 1.07G (8 bits+FRC)
• Horizontal frequency: 30-135KHz
• Active area W x H: 2141 x 903 mm, 84.3 x 35.6
• Frame width: 14.9 x 14.9 x 14.9 mm
• Pixel pitch: 0.13945 x 0.41835 mm
• Digital video input: HDMI x1 (5120x2160 @60Hz, HDMI 2/3/4 x3: 3840x2160 60Hz), DP x1 (5120x2160 60Hz), USB-C x1 (3840x2160 60Hz)
• Audio input: Mini Jack x1 (3.5mm)
• Monitor control input: RJ45 (LAN) x2 (1000Mbps), RS-232c x1
• Digital video output: HDMI x1 (max resolution 3840x2160 @60 HDMI 2.0 HDCP 1.4)
• Audio output: Mini Jack x1 (3.5mm)
• Speakers: 2 x 20W (20W subwoofer)
• Monitor control output: OPS slot x1 (Intel OPS 80pin)
• USB ports: x3 (1x side (Android only), 2x side + 2x top (public, can automatically switch to current channel) USB 3.2 Gen1)
• RJ45 (LAN): x2
• USB hub: x1
• Wi-Fi: yes (WiFi 6E + BT 5.2)
• Hardware SOC: RK3588 Octo-core A76x4 + A55x4, GPU Mali G640 MP4, RAM: 8GB, ROM: 128GB
• Extra: Intel OPS 80pin
• Kiosk mode: yes
• Max operating time: 24/7
• Housing type (front frame): Metal
• OSD menu languages: EN, DE, FR, ES, IT, RU, CN, CZ, NL, PL, JP, CAT, FI, DA, ET, LV, LT, HU
• Blue light reduction: yes
• Flicker-free LED: yes
• Plug & Play: DDC2B
• Orientation: landscape, portrait
• VESA standard: 800 x 600 mm
• Operating temperature range: 0°C-40°C
• Storage temperature range: -20°C-60°C
• Power supply: AC 100-240V, 50/60Hz
• Power supply: internal
• Power consumption: 201W typical, 0.5W standby, 0.3W off
• Regulations: CB, CE, TÜV-Bauart, EAC, RoHS Support, ErP, WEEE, REACH, UKCA
• Energy efficiency class: G
• REACH SVHC: contains lead over 0.1%
• Dimensions W x H x D: 2182 x 943.8 x 85.2 mm
• Weight: 44 kg
