Iluminador infravermelho externo LIR-IB88 IR LAB, 850nm, 88 LEDs, alcance de 80m, IP66, 12V DC

The LIR-IB88 IR LAB is a high-performance external infrared spotlight designed for professional surveillance applications. With 88 high-power IR LEDs operating at 850nm, it provides covert illumination up to 80 meters, making it ideal for both indoor and outdoor security systems. The robust aluminum alloy housing and IP66 rating ensure reliable operation in harsh weather conditions.

Advantages

• Long-range illumination up to 80 meters
• Covert infrared with faint red glow for discreet monitoring
• Built-in CDS light sensor for automatic on/off control
• Durable aluminum alloy housing with IP66 protection
• Adjustable U-bracket for flexible mounting

Suitable for

• Outdoor CCTV systems requiring night vision enhancement
• Perimeter security and large area surveillance
• Indoor warehouses and parking lots
• Low-light environments needing reliable IR illumination

Key specifications

• IR Wavelength: 850 nm
• Number of IR LEDs: 88
• Illumination Range: Up to 80 meters
• Beam Angle: 60 degrees
• Power Input: DC 12V
• Current Draw: 2A
• Power Consumption: 20W
• Ingress Protection: IP66
• Housing Material: Aluminum Alloy
• Operating Temperature: -20°C to +50°C
• Light Sensor: Built-in CDS (Auto On/Off)
• IR LED Life: 20,000 hours
• Mounting Type: Adjustable U-bracket
• Infrared Type: Covert (faint red glow)
• Application: Outdoor / Indoor

Recommendations

For optimal performance, use with a regulated DC 12V power supply capable of at least 2A. Ensure the spotlight is mounted securely using the included U-bracket and positioned to cover the desired area without obstructions.
