Injetor PoE Gigabit VIVOTEK AP-FXC-0210 30W IEEE 802.3af/at 48V DC

Deliver up to 30W of power over Gigabit Ethernet with the VIVOTEK AP-FXC-0210, a single-port midspan injector that combines data from a non-PoE switch with 48V DC power over one Cat5e/6 cable. Ideal for IP cameras, wireless access points, and VoIP phones.

Overview

The AP-FXC-0210 is a compact power injector that enables PoE on existing networks without replacing switches. It supports 10/100/1000 Mbps data rates, ensuring no bottleneck for high-resolution video streams. The injector is powered by an included external 100-240V AC adapter, suitable for worldwide use.

What stands out

• Full IEEE 802.3af/at compliance with 30W maximum output
• Gigabit Ethernet passthrough for high-bandwidth devices
• Mode B power injection (pins 4/5+ and 7/8-) for compatibility
• Compact plastic housing with desktop or wall-mount options
• LED indicators for power and PoE status
• Over-current, over-voltage, and short-circuit protection

Technical details

• Input: 100-240V AC, 50/60 Hz (via external adapter)
• Output: 48V DC, up to 30W
• Data rate: 10/100/1000 Mbps
• Connectors: 1x RJ-45 data in, 1x RJ-45 data+power out
• Operating temperature: 0°C to 40°C (32°F to 104°F)
• Operating humidity: 10% to 90% non-condensing
• Certifications: CE, FCC, RoHS
• Idle power consumption: less than 2W

Our verdict

The VIVOTEK AP-FXC-0210 is a reliable and efficient way to add PoE capability to an existing network without replacing switches. Its Gigabit passthrough and robust protection features make it a solid choice for powering IP devices.
