Intercomunicador áudio Fanvil I10S preto metálico com fios IP54

The Fanvil I10S audio intercom system is a wired, wall-mountable unit with a black metallic finish and IP54 protection against dust and splashes. Designed for residential and commercial use, the device supports HD audio codecs G.722 and Opus for clear voice transmission and includes a built-in audio line-out to connect an active speaker for background music or amplified announcements.

Advantages

The I10S delivers improved intercom clarity through support for G.722 and Opus HD audio codecs. Its IP54 rating provides protection in semi-exposed environments, and the integrated audio line-out enables playback through external speakers. The wired connection offers stable communication suitable for security and access-control installations.

Suitable for

• Residential entry systems and apartment intercoms
• Office reception and access control points
• Commercial buildings and retail entrances
• Areas requiring background music or amplified paging via external speaker

Key specifications

• Brand: Fanvil
• Model: I10S
• Form factor: Wired, wall-mountable
• Finish: Black metallic
• Ingress protection: IP54
• Audio codecs: G.722, Opus
• Audio interface: Built-in audio line-out for external speaker
• Category: Control systems / audio intercom
• MPN: I10S
• EAN: 6937295602593

How to use

Mount the Fanvil I10S on a suitable wall surface and connect it to the building network and power according to installation guidelines. Configure SIP and audio settings using the device web interface or provisioning server to enable HD audio codecs (G.722, Opus). Connect an active speaker to the line-out port if background music or louder paging is required. Test calls and audio playback after setup to verify clarity and volume.

Recommendations

For reliable audio performance, use shielded network cabling and ensure the unit is installed in a location protected from direct exposure to heavy rain. If using external speakers, verify impedance and power compatibility with the line-out output to avoid distortion.
