JOINT RSS-60-300 PG Conector reto de baixa tensão com gel, 60-300 mm², IP68

The JOINT RSS-60-300 PG is a high-quality, gel-filled low voltage straight joint designed for reliable and durable connections of polymeric insulated cables. Suitable for copper and aluminum conductors, this joint accommodates a wide cross-section range of 60-300 mm² per core and supports up to 5 cores. With an IP68 rating, it is ideal for underground, submerged, overhead, indoor, and outdoor installations. The re-enterable gel allows for easy re-access, and the joint is UV resistant and halogen-free, ensuring long-term performance in demanding environments.

Advantages

This joint offers exceptional versatility and protection. The pre-filled gel technology provides immediate sealing against moisture and contaminants, while the robust plastic housing withstands mechanical stress. Its re-enterable design simplifies maintenance and upgrades. Compliance with EN 50393 and VDE 0278 standards guarantees safety and reliability.

Suitable for

• Low voltage power distribution networks
• Underground cable connections
• Submersible pump installations
• Outdoor lighting and infrastructure
• Industrial and commercial electrical systems

Key specifications

• Application: Low Voltage Straight Joint
• Joint Technology: Gel-filled (Pre-filled Gel)
• Cable Type: Polymeric insulated (XLPE, EPR)
• Conductor Material: Copper, Aluminum
• Conductor Cross-section: 60-300 mm² (per core)
• Voltage Rating: Up to 1 kV
• Number of Cores: 1, 2, 3, 4, 5
• IP Rating: IP68
• Operating Temperature: -20°C to +90°C
• UV Resistant: Yes
• Halogen-free: Yes
• Re-enterable: Yes
• Standards: EN 50393, VDE 0278

Recommendations

For optimal performance, use with appropriate mechanical or crimp connectors (not included). Ensure proper cable preparation and follow installation guidelines. Suitable for direct burial and continuous immersion.
