JUNG Botão HOME 1 módulo

The JUNG Push Button HOME 1-Gang (model BTA17101SWM) is a high-quality momentary contact switch insert designed for reliable control of lighting, bell systems, and door openers. Manufactured by JUNG, a trusted brand in electrical installations, this 1-gang push button features a normally open (NO) contact and is suitable for flush mounting. It is compatible with JUNG AS, A, CD, LS, and SL series frames, offering flexibility for various design aesthetics.

Advantages

This push button provides a clean, modern solution for momentary switching applications. Its screw terminals ensure secure and easy wiring, while the thermoplastic housing guarantees durability and halogen-free construction. With an IP20 protection rating, it is ideal for indoor use in dry environments.

Suitable for

• Lighting control in residential and commercial buildings
• Bell systems and door openers
• Integration with JUNG frame series (AS, A, CD, LS, SL)

Key specifications

• Product Type: Push-button switch insert
• Number of Gangs: 1-gang
• Switch Function: Momentary contact (Taster)
• Contact Type: Normally Open (NO) / Schließer
• Rated Voltage: 250 V AC
• Rated Current: 10 A
• Connection Type: Screw terminals
• Mounting Type: Flush-mounted (Unterputz)
• Material: Thermoplastic
• Protection Class: IP20
• Halogen-free: Yes
• Operating Temperature: 0 to 40 °C
• Number of Terminals: 2

Recommendations

For optimal performance, pair this push button with compatible JUNG frames and ensure proper flush mounting. Always adhere to local electrical codes during installation.
